The VueGuard 930 C is a general-purpose, optical clear, UV curable anti-fog coating.It survives washing with multipurpose water and alcohol-based cleaners as well as, oxidative, strongly basic and acidic cleaners.
The VueGuard 930 C-AM offers both Anti-Fog and Anti-Microbial properties that inhibit the ability of microbes to grow and minimizes the spread of disease.
The VueGuard 930 PST is the recommended AF Post Surface Treatment used to clean, remove dirt, oils, and other contaminants. It also maintains the anti-fog properties of the treated article for an exceptionally long time.
This coating has adhesion to technical thermoplastics. It is three times better in scratch resistance and will survive three hours at 140°C without total loss of anti-fog properties.
It was also formulated to be capable of being washed multiple times with alcohol based cleaners.
Coating Applications
- Industrial
- Home
- Hospitality
- Automotive
- Commercial
VueGuard 930 C Technical Data Sheet
•Materials:
The VueGuard 930C UV-curable
AF coating can be used with PC,
PMMA, PET, and other optical
clear thermoplastic materials.
Coating Application Process:
•% Solids:
Spray-25%, Dip & Flow-40%
and Roll-to-Roll-75%
•UV Dosage Energy:
1200 mJ/cm2
•UV-cure thermal exposure
to 70 -100˚ C increases coating
durability and solvent rub
resistance.
•Masking:
Mask AF-coated surface with
paper or film without adhesives.
| Fogging Test | |
|---|---|
| Hot Fog(1)- Time to Fog | >30 Minutes |
| Cold Fog(2)- Time to Fog | >No Fogging |
| Cold Fog(3)- Time to Fog | >30 Minutes |
1. Test sample placed over 300ml beaker filled with 250ml of water at 60°C
2. Test sample kept in freezer at -10°C for 45 min and observed for fogging at 25°C.
3. Test sample kept in freezer at -10°C for 60 min and tested for hot fogging(1)
| Mechanical Properties | |
|---|---|
| Adhesion [%] (4) | 100% |
| Scratch Resistance [psi] (5) | 2 |
| Pencil Hardness (6) | B |
| Taber Abrasion [%] (7) | 14% |
| Bayer Ratio (8) | 1.5 |
4. ASTM D-3359
5. Steel wool rotary testing using 1.25 square inch #0000 steel wool at 2.5 lbs
for 5 revolutions.
6. ASTM D-3363, modified Mitsubishi Hi Uni pencils at 500g load and 45° angle
7. ASTM D 1044, CS-10, 500g load, 100 cycles, Kryptonite B
8. ASTM F 735
| Hot Water/ High Temperature Resistance Tests | |||
|---|---|---|---|
| Untreated | Water Immersion (11) | High Temperature (12) | |
| Light Transmittance [%] (9) | 100% | 100% | 100% |
| Haze (9) | 0 | 0 | 0 |
| Yellowness Index (10) | 0.4 | 0 | 0.1 |
| Adhesion (4) | 100% | 100% | 100% |
9. ASTM D 1003-61
10. ASTM D-1925
11. Coated sample is immersed in boiling water for 30 min.
12. Coated sample tested after 5 hours at 100°C.
| Cleaning Test( 13) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Before Test No Fog 1-30 sec |
Cycle 1 No Fog 1-30 sec |
Cycle 2 No Fog 1-30 sec |
Cycle 3 No Fog 1-30 sec |
Cycle 4 No Fog 1-30 sec |
Cycle 5 No Fog 1-30 sec |
Cycle 6 No Fog 1-30 sec |
Cycle 7 No Fog 1-30 sec |
Cycle 8 No Fog 1-30 sec |
Cycle 9… No Fog 1-30 sec |
Cycle 50 No Fog 1-30 sec |
13. Samples were sprayed with Windex then wiped clean with a dry scratch free rag.
Anti-fog properties were tested after each cycle for hot fogging (1).
PCI LABS assumes no obligation or liability for any information furnished by it or results obtained with respect to these products. All such advice is given and accepted at the buyer’s risk. Users should be governed by their own tests, made under conditions representative of those to which the product will be subjected in actual service. Users assume all risks and responsibilities associated with the proper handling, use and disposal of the material.
